Like the E816, the E817/F Set-Back Thermostat regulates room temperatures to two different temperature setpoints, a lower temperature ‘Set-Back’ and a higher boost temperature ‘Setpoint’. A pushbutton on the side of the unit allows the user to select between the two levels, while LED indicators illuminate to clearly identify which mode the unit is in.

In addition to this set-back functionality the E817/F incorporates a timeout while in the high/boost mode. It automatically reverts back to regulating the temperature to the lower ‘Setback’ mode after the pre-selected timeout period (anything between 0.25 and 8 hours) has expired, thus helping to reduce overall energy consumption.

Full adjustment of the two temperature levels and timeout can be achieved only through adjusting internal thumbwheels located inside the tamperproof unit, so preventing unauthorised modification to the thermostat’s configuration.

Additional delay periods can easily be accommodated, please call our sales team for further information on our customisation service.

Frost (/F)
This thermostat offers a much lower thermostatic control range of -2°C to +12°C. The unit operates as normal but has a lower temperature setpoint, primarily used for frost protection.
